China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth

China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth

    • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth
    • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth
    • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth
    • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth
    • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth
  • China Hot Popular Tractor Mounted Mobile Water Well Drilling Rig For 100m Depth

    Product Details:

    Place of Origin: China
    Certification: ISO9001-2000
    Model Number: CST-150T,200T,300T

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: US+100+set
    Packaging Details: Nude packing
    Delivery Time: one month
    Payment Terms: T/T
    Supply Ability: 500 a quarter
    Contact Now
    Detailed Product Description

                                                     Tractor Mounted Water Well Drilling Rig





    Technical Specifications





    model CST-150T CST-200T CST-300T
    Power 22.1KW 37KW 44.2KW
    Drilling Depth 150 m 200 m 300 m
    Drilling hole diameter 90-235 mm 90-235 mm 130-325 mm
    Working pressure 0.7-2.5MPa 0.7-2.5MPa 1.05-3.0MPa
    Carriage stroke 1800/2000 1800/2000 mm 2400/3400 mm
    Max. torque 3500 N.m 4500 N.m 6500N.m
    Boost speed 20m/min 20m/min 20m/min
    Rotation speed 60-80rpm 80/160 rpm 80/160 rpm
    Drilling pipe length 1500 mm 1500 mm 2000/3000 mm
    Static height 1950 mm 2150 mm 3300 mm
    Adapt to rock hardness F=6-20 F=6-20 F=6-20
    Air consumption 5-30m³/h 5-30m³/h 5-35m³/h
    Min.ground clearance 400 mm 400 mm 400 mm
    Lifting force 39200N 58800N 88200N
    Climbing angle 30° 30° 30°
    Drilling efficiency 10-35m/h 10-35m/h 15-35m/h
    Drilling pipe diameter 76 mm 76/89 mm 76/89 mm
    Total weight 2300(including tractor) 2700(including tractor) 6200(including tractor)
    Overall dimension 3300*1350*1950 mm 3350*1450*2100mm 3900*1850*3300 mm
    Fit DTH hammer 4/5/6 inches 4/5/6 inches 5/6/8 inches
    Recommended air compressor 18m³/1.7 MPa 20m³/2.0 MPa 900-1200
