TGQ-30 Portable Type Core Drilling Rig for Mountain Area
ADD: NO.1 Kuaileli, Xiaolongkan Street, Shapingba District, Chongqing China;
Contact person: Lucy Fang; Skype: lucyfang9 , Website: www.lucydrillingrig.com email: lucyfang15@yahoo.com; Mobile: +86-13628481197 TEL.:+86-15111813754 ; +86-15923510719
1. APPLICATIONS AND FEATURES:
TGQ-50 sampling rig uses hydraulic drive, has features of stable performance, small vibration, low noise, and high reliability.The rig is composed by pump hydraulic power and host.Rig has less wearing parts and easy on- site maintenance.Host with a transmission, can achievediamond drilling, alloy drilling and spiral drilling for rock sampling and soil sampling.Rig structure is compact, convenient to carry.
Technical Specifications
-Drilling hole dia.: 40/46 (mm)
-Spindle speed: 150/600 (rpm)
-Machine weight: 90 (kg)
-Pump weight: 81/105 (kg)
-Drilling Frame Type: Single-column oblique support
-Drilling mode: Chain sprocket
-Frame running: 1.2 (m)
-Frame height: 1.65 (m)
-Hand wheel and gear ratio: 1:30
-Max.lifting force: 750 (kg)
