| Place of Origin: | China |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | polywooden package |
| Delivery Time: | stocked |
| Payment Terms: | T/T |
Technical Specifications
|
Type |
Horizontal, double cylinder, double Acting Reciprocating Piston Pump |
||
|
Stroke (mm) |
260 |
||
|
Cylinder Bore (mm) |
140(850/5A); 130(600/6A),;95(350/8A) |
||
|
Pump Speed min-1) |
66 |
||
|
Discharge (l/min) |
850 |
600 |
350 |
|
Pressure (MPa) |
5.0 |
6.0 |
8.0 |
|
Volume Efficiency (%) |
85 |
||
|
Total Efficiency (%) |
72 |
||
|
Suction Height (m) |
|
||
|
Suction Pipe Inner Dia.(mm) |
152 |
||
|
Discharge Pipe Dia.(mm) |
64 |
||
|
Driving Power (KW) |
YB280M-4 electric motor 90 kW, or 6135T diesel engine |
||
|
Speed of V-pulley (r/min) |
375 |
||
|
Diameter Of V- Pulley (mm) |
918 |
||
|
V-belt |
C-6300 7 PCS |
||
|
Dimension (mm)(length×wide ×height) |
Pump:3018*1120*2050 |
||
|
Weight(kg) |
Pump:3100 excluding power unit
|
||
|
|
|
||
|
|
|
||
