China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig

China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig

    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
    • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig
  • China Hot Multifunction MGY-100BW Excavator Mounted soil and rock anchor drilling rig

    Product Details:

    Place of Origin: ChongQing
    Certification: ISO-9001-2008
    Model Number: MGY-100BW

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: 6000USD
    Packaging Details: nude
    Delivery Time: 30 Days
    Payment Terms: T/T, L/C or ohers
    Supply Ability: 1000 sets per year
    Contact Now
    Detailed Product Description

     MGY-100BW Excavator Mounted Drilling Rig


    ADD: NO.1 Kuaileli, Xiaolongkan Street, Shapingba District, Chongqing China;
    Skype: lucyfang9 ; Website: www.lucydrillingrig.com, email: lucyfang16@yahoo.com;
    M: +86-13628481197 TEL.:+86-15923510719,15111813754 FAX:0086-23-65311383


    Ⅰ. Application:
        MGY-100BW full hydraulic drilling rig is developed based on DH220 excavator, specially designed to adapt to high slope, deep foundation pit construction engineering. The drilling method is mainly positive, Reverse Circulation DTH hammer drilling, and earth auger drilling as well, but also can be applied to self-drilling anchor bolt, anchor cable, deep foundation pit and tunnel pipe shed construction.

    Ⅱ.Features:
    1.remove the excavator’s short arm, the mast of the rig is mounted on the excavator longer arm. Working oil circuit of the excavator is connected with the drilling rig through the original excavator crusher’s oil way, without any modification on the excavator, whicn can meet the needs of the drilling rigs. To achieve the multi-purpose of one machine.

    2. construction of a wide range, the construction height up to a maximum of 7m or so, no need to build scaffold, can drill at certain height.

    3 there is a operation platform on the drill mast, it is easy for an operator to control the drilling rig and put on drill rod in close distance.

    4 drilling rig with hydraulic breakout device, reduce labor intensity

    .

    Ⅲ. Technical specifications:



    Power

    Form excavator.

    drilling hole diameter

    Φ110mm—Φ350mm

    drilling depth

    150m-40m

    the max.drill rod length

    Φ89x4000

    hydraulic system pressure

    safety pressure 25Mpa;rotation pressure 20MPa;feed pressure 14Mpa

    Torque(diesel engine of excavator 1200rpm)

    Option 1   6350N.m(50r/min); 3250N.m(100 r/ min)

    Option 2   3250N.m(100r/min); 1650N.m(200 r/ min)

    Inner diameter of chuck

    Φ110 mm

    pulling/pushing speed

    0—0.26m/s

    pulling/pushing force

    85/60KN

    Feed stroke

    4200mm or 4200 mm + suspension 3000 mm =7200mm

    Drilling angle

    0-180º

    compensation length of auxiliary mast

    1200mm

    Max. Horizontal height of drilling

    About 7000-8000mm
